• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Datum Diameter (A)	9
Material	Cast Iron
Overall Length (in)	4.75 in
Pitch Diameter (B)	9.7
Pulley Material	Cast Iron
Pitch Diameter (A)	9.2
Number of Grooves	6
Bushing Used	R1
Datum Diameter (B)	9.4
Outside Diameter (in)	9.75 in
Bore (Min) (in)	1.125 in
Belt Section	A, B
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Keyway Size	.750
Overall Width (in)	4.75
Face Width (in)	4.75
Pulley Construction	Webbed
Bushing Bore Range	1.125 - 3.750

General Specifications

UPC	662289144907
Weight	40.94 LB
Packaged Length	10.20 IN
Packaged Width	10.40 IN
Packaged Height	5.10 IN
