• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Overall Length (in)	4.75 in
Bushing Used	R1
Material	Cast Iron
Datum Diameter (A)	8.2
Outside Diameter (in)	8.95 in
Pitch Diameter (A)	8.4
Datum Diameter (B)	8.6
Pulley Material	Cast Iron
Pitch Diameter (B)	8.9
Number of Grooves	6
Product Type	Multiple Sheaves
Bore (Min) (in)	1.125 in
Belt Section	A, B
Bore Type	Split Taper Bushed
Keyway Size	.750
Pulley Construction	Webbed
Bushing Bore Range	1.125 - 3.750
Face Width (in)	4.75
Overall Width (in)	4.75

General Specifications

UPC	662289114801
Weight	32.12 LB
Packaged Length	9.06 IN
Packaged Width	9.06 IN
Packaged Height	4.75 IN
