• Combination Groove - All Browning B5V Sheaves permit the running of A, 4L, B, 5L and 5V Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Broad horsepower coverage - The B5V is available in 1 through 6 grooves allowing it to cover from 5 to 125 horsepower drives
• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• New Casting design - The B5V castings were developed using CAD and Finite Elements Analysis to determine where to add and eliminate material.

Technical Specifications

Bushing Used	Q1
Number of Grooves	6
Pitch Diameter (5V)	6.9
Outside Diameter (in)	7.08 in
Material	Cast Iron
Model Name	6B5V-SheaveMaster
Datum Diameter (B)	6.8
Pulley Material	Cast Iron
Overall Length (in)	4.921875 in
Datum Diameter (A)	6.4
Pitch Diameter (B)	7.1
Pitch Diameter (A)	6.6
Belt Section	A, B, 5V
Product Type	Multiple Sheaves
Bore (Min) (in)	0.75 in
Bore Type	Split Taper Bushed
Keyway Size	.500
Face Width (in)	4.5938
Bushing Bore Range	2.6875 - 2.6875
Overall Width (in)	5.625
Pulley Construction	Plain

General Specifications

UPC	662460344782
Weight	19.26 LB
Packaged Length	7.60 IN
Packaged Width	7.70 IN
Packaged Height	5.10 IN
