• Combination Groove - All Browning B5V Sheaves permit the running of A, 4L, B, 5L and 5V Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Broad horsepower coverage - The B5V is available in 1 through 6 grooves allowing it to cover from 5 to 125 horsepower drives
• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• New Casting design - The B5V castings were developed using CAD and Finite Elements Analysis to determine where to add and eliminate material.

Technical Specifications

Pitch Diameter (A)	5.6
Pitch Diameter (B)	6.1
Material	Cast Iron
Datum Diameter (A)	5.4
Number of Grooves	6
Model Name	6B5V-SheaveMaster
Number of Hubs	1
Belt Type	Classic or 358
Pitch Diameter (5V)	5.9
Outside Diameter (in)	6.08 in
Bushing Used	Q1
Datum Diameter (B)	5.8
Overall Length (in)	4.921875 in
Pulley Material	Cast Iron
Number of Flanges	7
Product Type	Multiple Sheaves
Bore (Min) (in)	0.75 in
Belt Section	A, B, 5V
Bore Type	Split Taper Bushed
Bushing Bore Range	2.6875 - 2.6875
Keyway Size	.500
Face Width (in)	4.5938

General Specifications

UPC	662460344737
Weight	13.99 LB
Packaged Length	7.30 IN
Packaged Width	7.10 IN
Packaged Height	5.00 IN
