• Combination Groove - All Browning B5V Sheaves permit the running of A, 4L, B, 5L and 5V Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Broad horsepower coverage - The B5V is available in 1 through 6 grooves allowing it to cover from 5 to 125 horsepower drives
• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• New Casting design - The B5V castings were developed using CAD and Finite Elements Analysis to determine where to add and eliminate material.

Technical Specifications

Bushing Used	Q2
Datum Diameter (B)	5.6
Material	Cast Iron
Model Name	6B5V-SheaveMaster
Pitch Diameter (B)	5.9
Datum Diameter (A)	5.2
Number of Grooves	6
Pitch Diameter (5V)	5.7
Outside Diameter (in)	5.88 in
Pulley Material	Cast Iron
Overall Length (in)	5.671875 in
Pitch Diameter (A)	5.4
Belt Section	A, B, 5V
Bore (Min) (in)	1 in
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Keyway Size	.500
Bushing Bore Range	1.000 - 2.625

General Specifications

UPC	662460344720
Weight	16.58 LB
Packaged Length	6.06 IN
Packaged Width	6.06 IN
Packaged Height	4.75 IN
HTC	8483.50.9040
Country of Origin	Mexico
