• Combination Groove - All Browning B5V Sheaves permit the running of A, 4L, B, 5L and 5V Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Broad horsepower coverage - The B5V is available in 1 through 6 grooves allowing it to cover from 5 to 125 horsepower drives
• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• New Casting design - The B5V castings were developed using CAD and Finite Elements Analysis to determine where to add and eliminate material.

Technical Specifications

Number of Grooves	6
Material	Cast Iron
Outside Diameter (in)	11.28 in
Model Name	6B5V-SheaveMaster
Pulley Material	Cast Iron
Bushing Used	R1
Overall Length (in)	4.59375 in
Datum Diameter (B)	11
Datum Diameter (A)	10.6
Pitch Diameter (5V)	11.1
Pitch Diameter (A)	10.8
Pitch Diameter (B)	11.3
Belt Section	A, B, 5V
Bore (Min) (in)	1.125 in
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Bushing Bore Range	1.125 - 3.750
Face Width (in)	4.5938
Pulley Construction	Webbed
Overall Width (in)	4.59375
Keyway Size	.750

General Specifications

UPC	662460344577
Weight	38.00 LB
Packaged Length	11.60 IN
Packaged Width	11.70 IN
Packaged Height	5.00 IN
