• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Bushing Used	R1
Material	Cast Iron
Pulley Material	Cast Iron
Number of Grooves	6
Datum Diameter (B)	15.4
Overall Length (in)	4.75 in
Datum Diameter (A)	15
Outside Diameter (in)	15.75 in
Pitch Diameter (B)	15.7
Pitch Diameter (A)	15.2
Belt Section	A, B
Product Type	Multiple Sheaves
Bore (Min) (in)	1.125 in
Bore Type	Split Taper Bushed
Keyway Size	.750
Overall Width (in)	4.75
Face Width (in)	4.75
Bushing Bore Range	1.125 - 3.750
Pulley Construction	Spoked

General Specifications

UPC	662289105182
Weight	51.84 LB
Packaged Length	15.75 IN
Packaged Width	15.75 IN
Packaged Height	4.75 IN
