• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Material	Cast Iron
Pitch Diameter (A)	12.2
Pitch Diameter (B)	12.7
Pulley Material	Cast Iron
Datum Diameter (A)	12
Number of Grooves	6
Overall Length (in)	4.75 in
Datum Diameter (B)	12.4
Outside Diameter (in)	12.75 in
Bushing Used	R1
Bore (Min) (in)	1.125 in
Belt Section	A, B
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Face Width (in)	4.75
Overall Width (in)	4.75
Pulley Construction	Spoked
Bushing Bore Range	1.125 - 3.750
Keyway Size	.750

General Specifications

UPC	662289215003
Weight	40.40 LB
Packaged Length	12.75 IN
Packaged Width	12.75 IN
Packaged Height	4.75 IN
