• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Bushing Used	SD
Material	Cast Iron
Model Name	65V_LG_Sheavemaster
Pulley Material	Cast Iron
Outside Diameter (in)	4.9 in
Number of Grooves	6
Pitch Diameter (5V)	4.8
Belt Section	5V
Product Type	Multiple Sheaves
Bore (Min) (in)	0.5 in
Bore Type	QD Bushed
Pulley Construction	Solid
Bushing Bore Range	0.500 - 2.000
Overall Width (in)	4.4375
Face Width (in)	4.4375
Length Through Bore (in)	1.8125 in

General Specifications

UPC	662289468898
Weight	9.70 LB
Packaged Length	6.06 IN
Packaged Width	6.06 IN
Packaged Height	4.75 IN
HTC	8483.50.9040
Country of Origin	Mexico
