• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Number of Grooves	6
Outside Diameter (in)	21.2 in
Number of Flanges	7
Number of Hubs	1
Model Name	65V_LG_Sheavemaster
Material	Cast Iron
Belt Type	Classic or 358
Pulley Material	Cast Iron
Pitch Diameter (5V)	21.1
Bushing Used	F
Product Type	Multiple Sheaves
Belt Section	5V
Bore (Min) (in)	1 in
Bore Type	QD Bushed
Face Width (in)	4.4375
Bushing Bore Range	1.000 - 4.000
Length Through Bore (in)	3.61 in

General Specifications

UPC	662289343966
Weight	96.00 LB
Packaged Length	21.20 IN
Packaged Width	21.20 IN
Packaged Height	4.47 IN
