• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Bushing Used	E
Pulley Material	Cast Iron
Pitch Diameter (5V)	11.2
Number of Grooves	6
Outside Diameter (in)	11.3 in
Material	Cast Iron
Model Name	65V_LG_Sheavemaster
Bore (Min) (in)	0.875 in
Belt Section	5V
Product Type	Multiple Sheaves
Bore Type	QD Bushed
Face Width (in)	4.4375
Pulley Construction	Spoked
Bushing Bore Range	0.875 - 3.500
Length Through Bore (in)	2.75 in

General Specifications

UPC	662289470051
Weight	38.59 LB
Packaged Length	11.80 IN
Packaged Width	11.80 IN
Packaged Height	5.00 IN
