• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Width (mm)	25.4 mm
Number of teeth	60
Product Type	Gearbelt Pulley
Bore Range	1/2 to 1 3/4
Material	Cast Iron
Bore Type	Bushed Bore
Belt Section	L
Inside Diameter (in)	6.4375 in
Pitch Diameter (in)	7.162 in
Outside Diameter (mm)	181.1528 mm
Width (in)	1 in
Outside Diameter (in)	7.132 in
Face Width	1.25
Number of Hubs	1
Hub Diameter (in)	3 in
Pulley Construction	Arm
Overall Length (in)	2.29725 in
Length Through Bore	1.938
With Flanges	No Flanges
Hub Projection	0.5

General Specifications

UPC	662289314485
Weight	6.33 LB
Packaged Length	7.30 IN
Packaged Width	7.30 IN
Packaged Height	1.40 IN
HTC	8483.50.9080
Country of Origin	United States of America
