• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Product Type	Gearbelt Pulley
Number of teeth	60
Model Name	GBPulley_Master5
Bore Range	3/4 to 2 11/16
Width (mm)	25.4 mm
Bore Type	Bushed Bore
Material	Cast Iron
Pitch Diameter (in)	9.549 in
Belt Section	H
Outside Diameter (in)	9.495 in
Width (in)	1 in
Outside Diameter (mm)	241.173 mm
Inside Diameter (in)	8.6875 in
Face Width	1.25
With Flanges	No Flanges
Hub Diameter (in)	4.125 in
Hub Projection	1.2502
Length Through Bore	2.5
Pulley Construction	Arm
Overall Length (in)	2.78125 in
Number of Hubs	1

General Specifications

UPC	662289314515
Weight	10.82 LB
Packaged Length	10.30 IN
Packaged Width	10.20 IN
Packaged Height	2.70 IN
HTC	8483.50.9080
Country of Origin	United States of America
