• No Maintenance Needed: The latest TorqTitan™ V-Belts need no re-tensioning or maintenance after installation.
• Increased Power: With 30% more horsepower, they enable smaller, cost-effective drive designs.
• Durable Material: Constructed from EPDM material, they operate reliably in temperatures from -40°F to 248°F.
• Precision Matching: The "Code 1" Match belt system exceeds RMA* standards, minimizing vibration and noise.
• Enhanced Grip: Raw-edge sidewalls enhance grip for smoother, quieter performance.
• <i>*RMA = Rubber Manufacturers Association</i>

Technical Specifications

Type	TorqTitan Notched V-Belts
Belt Section	5VX
Material	EPDM
Efficiency (%)	0.98
Product Type	Notched Belt
Outside Length/Diameter (in)	69 in
Operating Temperature [Max] ºC	120 °C
Outside Diameter (in)	69 in
Operating Temperature [Max] ºF	251 °F
Height	0.53
Reinforcing cord material	Polyester
Number of Ribs	1
Standards met	MPTA IP-20;RMA
Construction Type	Cogged
Section Size	5VX
Belt Series	TorqTitan
Width (in)	0.625 in
Pitch Length	69
Resistance Features	Oil & Chemical per ARPM IP-3-2, Static Dissipating per ISO1813
Operating Temperature Range	-40 to +251 °F

General Specifications

UPC	662289056026
Weight	0.65 LB
Packaged Length	5.40 IN
Packaged Width	9.85 IN
Packaged Height	2.05 IN
HTC	4010.32.3000
Country of Origin	United States of America
