• Browning 358 Wrapped Belts are constructed of Neoprene material wrapped top and botttom; operating temperature range of -30F to 140F degrees.
• More horsepower in less space - Browning 358 Belts provide more horsepower in the same span than conventional ABC Belts. This enables you to reduce drive cost.
• Greater Horsepower allows for smaller drive sheaves - Using 358 Belts can allow for smaller drive components while still meeting the drive requirements , thus lowering the overall drive cost.
• Close Belt tolerance - Browning Belts offer the "Code 1" Match belt system on all classical and "358" Belts, allowing easy selection of just one match number for each belt size. This ensures tighter than RMA standards.

Technical Specifications

Belt Section	5V
Type	358 Gripbelt
Material	Neoprene
Product Type	Wrapped Belt
Operating Temperature [Max] ºF	140 °F
Outside Length/Diameter (in)	236 in
Outside Length (in)	236 in
Efficiency (%)	0.95
Operating Temperature [Max] ºC	60 °C
Pitch Length	236
Standards met	ARPM IP-22
Number of Ribs	1
Width (in)	0.625 in
Construction Type	Wrapped
Height	0.531
Reinforcing cord material	Polyester
Belt Series	Narrow Series - Inch
Section Size	5V
Operating Temperature Range	-32 to +140 °F
Resistance Features	Oil & Chemical per ARPM IP-3-2, Static Dissipating per ARPM IP-3-3

General Specifications

UPC	662289157686
Weight	3.18 LB
Packaged Length	17.50 IN
Packaged Width	16.70 IN
Packaged Height	2.40 IN
HTC	4010.39.1000
Country of Origin	Mexico
