• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Number of Grooves	5
Pulley Material	Cast Iron
Model Name	5TC-L_Sheave_Master
Material	Cast Iron
Overall Length (in)	5.25 in
Datum Diameter (C)	8.8
Outside Diameter (in)	9.2 in
Pitch Diameter (C)	9.2
Bushing Used	Q2
Belt Section	C
Bore (Min) (in)	1 in
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Pulley Construction	Webbed
Bushing Bore Range	1.000 - 2.625
Keyway Size	.500
Overall Width (in)	5.25
Face Width (in)	5.25

General Specifications

UPC	662289233274
Weight	35.10 LB
Packaged Length	9.75 IN
Packaged Width	9.75 IN
Packaged Height	5.25 IN
