• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pitch Diameter (C)	9
Number of Grooves	5
Overall Length (in)	5.25 in
Pulley Material	Cast Iron
Material	Cast Iron
Model Name	5TC-L_Sheave_Master
Bushing Used	Q2
Outside Diameter (in)	9 in
Datum Diameter (C)	8.6
Bore (Min) (in)	1 in
Product Type	Multiple Sheaves
Belt Section	C
Bore Type	Split Taper Bushed
Bushing Bore Range	1.000 - 2.625
Overall Width (in)	5.25
Face Width (in)	5.25
Keyway Size	.500
Pulley Construction	Webbed

General Specifications

UPC	662289173136
Weight	32.37 LB
Packaged Length	9.06 IN
Packaged Width	9.06 IN
Packaged Height	5.25 IN
