• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Model Name	5TC-L_Sheave_Master
Material	Cast Iron
Pitch Diameter (C)	8.6
Belt Type	Classic or 358
Number of Hubs	1
Pulley Material	Cast Iron
Datum Diameter (C)	8.2
Number of Grooves	5
Bushing Used	Q2
Overall Length (in)	5.25 in
Outside Diameter (in)	8.6 in
Number of Flanges	6
Belt Section	C
Bore (Min) (in)	1 in
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Face Width (in)	5.25
Keyway Size	.500
Bushing Bore Range	1.000 - 2.625

General Specifications

UPC	662289310579
Weight	32.07 LB
Packaged Length	9.06 IN
Packaged Width	9.06 IN
Packaged Height	5.25 IN
