• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Bushing Used	Q2
Pitch Diameter (C)	8.2
Pulley Material	Cast Iron
Model Name	5TC-L_Sheave_Master
Outside Diameter (in)	8.2 in
Material	Cast Iron
Number of Grooves	5
Overall Length (in)	5.25 in
Datum Diameter (C)	7.8
Bore (Min) (in)	1 in
Belt Section	C
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Bushing Bore Range	1.000 - 2.625
Keyway Size	.500

General Specifications

UPC	662289122967
Weight	30.22 LB
Packaged Length	8.50 IN
Packaged Width	8.50 IN
Packaged Height	5.25 IN
