• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Number of Grooves	5
Model Name	5TC-S_Sheave_Master
Material	Cast Iron
Overall Length (in)	5.25 in
Pitch Diameter (C)	7.8
Datum Diameter (C)	7.4
Bushing Used	Q2
Pulley Material	Cast Iron
Outside Diameter (in)	7.8 in
Product Type	Multiple Sheaves
Bore (Min) (in)	1 in
Belt Section	C
Bore Type	Split Taper Bushed
Number of Hubs	1
Bushing Bore Range	1.000 - 2.625
Pulley Construction	Web
Overall Width (in)	5.25
Face Width (in)	5.25
Keyway Size	0.5

General Specifications

UPC	662289310524
Weight	30.40 LB
Packaged Length	7.88 IN
Packaged Width	7.88 IN
Packaged Height	5.25 IN
