• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pitch Diameter (C)	7.6
Material	Cast Iron
Outside Diameter (in)	7.6 in
Overall Length (in)	5.25 in
Number of Grooves	5
Pulley Material	Cast Iron
Bushing Used	Q2
Datum Diameter (C)	7.2
Model Name	5TC-S_Sheave_Master
Bore (Min) (in)	1 in
Belt Section	C
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Keyway Size	.500
Bushing Bore Range	1.000 - 2.625

General Specifications

UPC	662289272822
Weight	28.60 LB
Packaged Length	7.88 IN
Packaged Width	7.88 IN
Packaged Height	5.25 IN
HTC	8483.50.9040
Country of Origin	Mexico
