• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Datum Diameter (B)	9
Pitch Diameter (B)	9.3
Datum Diameter (A)	8.6
Pulley Material	Cast Iron
Model Name	5TB-L_Sheave_Master
Number of Grooves	5
Outside Diameter (in)	9.35 in
Bushing Used	Q2
Material	Cast Iron
Pitch Diameter (A)	8.8
Overall Length (in)	4.453125 in
Bore (Min) (in)	1 in
Belt Section	A, B
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Keyway Size	.500
Face Width (in)	4
Bushing Bore Range	1.000 - 2.625
Overall Width (in)	4.40625
Pulley Construction	Spoked

General Specifications

UPC	662289310418
Weight	30.62 LB
Packaged Length	11.00 IN
Packaged Width	10.50 IN
Packaged Height	4.40 IN
