• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pulley Material	Cast Iron
Overall Length (in)	4.453125 in
Outside Diameter (in)	8.35 in
Bushing Used	Q2
Material	Cast Iron
Model Name	5TB-L_Sheave_Master
Number of Grooves	5
Pitch Diameter (B)	8.3
Pitch Diameter (A)	7.8
Datum Diameter (A)	7.6
Datum Diameter (B)	8
Bore (Min) (in)	1 in
Belt Section	A, B
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Face Width (in)	4
Overall Width (in)	4.40625
Bushing Bore Range	1.000 - 2.625
Pulley Construction	Webbed
Keyway Size	.500

General Specifications

UPC	662289132058
Weight	24.60 LB
Packaged Length	9.10 IN
Packaged Width	9.10 IN
Packaged Height	4.30 IN
