• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Datum Diameter (B)	6.4
Pitch Diameter (A)	6.2
Pulley Material	Cast Iron
Overall Length (in)	4.328125 in
Datum Diameter (A)	6
Model Name	5TB-M_Sheave_Master
Bushing Used	Q1
Outside Diameter (in)	6.75 in
Material	Cast Iron
Number of Grooves	5
Pitch Diameter (B)	6.7
Product Type	Multiple Sheaves
Bore (Min) (in)	0.75 in
Belt Section	A, B
Bore Type	Split Taper Bushed
Pulley Construction	Webbed
Face Width (in)	4
Overall Width (in)	4.28125
Bushing Bore Range	2.6875 - 2.6875
Keyway Size	.500

General Specifications

UPC	662289310357
Weight	16.30 LB
Packaged Length	7.19 IN
Packaged Width	7.19 IN
Packaged Height	4.00 IN
