• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Material	Cast Iron
Pulley Material	Cast Iron
Number of Grooves	5
Datum Diameter (B)	6.2
Overall Length (in)	4.328125 in
Outside Diameter (in)	6.55 in
Datum Diameter (A)	5.8
Model Name	5TB-M_Sheave_Master
Pitch Diameter (B)	6.5
Bushing Used	Q1
Pitch Diameter (A)	6
Bore (Min) (in)	0.75 in
Product Type	Multiple Sheaves
Belt Section	A, B
Bore Type	Split Taper Bushed
Overall Width (in)	4.28125
Bushing Bore Range	2.6875 - 2.6875
Keyway Size	.500
Face Width (in)	4
Pulley Construction	Webbed

General Specifications

UPC	662289231751
Weight	15.25 LB
Packaged Length	6.63 IN
Packaged Width	6.63 IN
Packaged Height	4.00 IN
