• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Model Name	5TB-L_Sheave_Master
Pitch Diameter (A)	10.8
Pulley Material	Cast Iron
Outside Diameter (in)	11.35 in
Number of Grooves	5
Material	Cast Iron
Datum Diameter (B)	11
Overall Length (in)	4.453125 in
Pitch Diameter (B)	11.3
Datum Diameter (A)	10.6
Bushing Used	Q2
Belt Section	A, B
Product Type	Multiple Sheaves
Bore (Min) (in)	1 in
Bore Type	Split Taper Bushed
Overall Width (in)	4.40625
Face Width (in)	4
Pulley Construction	Spoked
Bushing Bore Range	1.000 - 2.625
Keyway Size	.500

General Specifications

UPC	662289282258
Weight	35.16 LB
Packaged Length	12.00 IN
Packaged Width	11.90 IN
Packaged Height	4.20 IN
