• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Outside Diameter (in)	21.2 in
Overall Length (in)	4.984375 in
Material	Cast Iron
Number of Grooves	5
Pulley Material	Cast Iron
Bushing Used	S1
Pitch Diameter (5V)	21.1
Bore (Min) (in)	1.6875 in
Belt Section	5V
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Pulley Construction	Spoked
Keyway Size	.750
Overall Width (in)	4.96875
Face Width (in)	3.75
Bushing Bore Range	1.6875 - 4.1875

General Specifications

UPC	662289241354
Weight	90.00 LB
Packaged Length	21.20 IN
Packaged Width	21.20 IN
Packaged Height	4.97 IN
