• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Outside Diameter (in)	9.75 in
Overall Length (in)	4.046875 in
Material	Cast Iron
Bushing Used	R1
Pulley Material	Cast Iron
Pitch Diameter (5V)	9.65
Number of Grooves	5
Bore (Min) (in)	1.125 in
Product Type	Multiple Sheaves
Belt Section	5V
Bore Type	Split Taper Bushed
Pulley Construction	Webbed
Face Width (in)	3.75
Bushing Bore Range	1.125 - 3.750
Keyway Size	.750
Overall Width (in)	4.03125

General Specifications

UPC	662289160792
Weight	31.28 LB
Packaged Length	10.40 IN
Packaged Width	10.60 IN
Packaged Height	4.20 IN
