• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Number of Grooves	5
Overall Length (in)	4.046875 in
Outside Diameter (in)	8 in
Pulley Material	Cast Iron
Material	Cast Iron
Bushing Used	R1
Pitch Diameter (5V)	7.9
Belt Section	5V
Product Type	Multiple Sheaves
Bore (Min) (in)	1.125 in
Bore Type	Split Taper Bushed
Pulley Construction	Webbed
Bushing Bore Range	1.125 - 3.750
Face Width (in)	3.75
Overall Width (in)	4.03125
Keyway Size	.750

General Specifications

UPC	662289120529
Weight	21.82 LB
Packaged Length	7.88 IN
Packaged Width	7.88 IN
Packaged Height	4.75 IN
