• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pitch Diameter (5V)	15.9
Pulley Material	Cast Iron
Outside Diameter (in)	16 in
Overall Length (in)	4.046875 in
Bushing Used	R1
Material	Cast Iron
Number of Grooves	5
Bore (Min) (in)	1.125 in
Belt Section	5V
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Pulley Construction	Spoked
Bushing Bore Range	1.125 - 3.750
Keyway Size	.750
Overall Width (in)	4.03125
Face Width (in)	3.75

General Specifications

UPC	662289131297
Weight	47.52 LB
Packaged Length	16.63 IN
Packaged Width	16.63 IN
Packaged Height	4.25 IN
