• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Bushing Used	Q2
Pitch Diameter (5V)	7.4
Number of Grooves	5
Outside Diameter (in)	7.5 in
Material	Cast Iron
Pulley Material	Cast Iron
Overall Length (in)	4.078125 in
Bore (Min) (in)	1 in
Product Type	Multiple Sheaves
Belt Section	5V
Bore Type	Split Taper Bushed
Keyway Size	.500
Pulley Construction	Webbed
Bushing Bore Range	1.000 - 2.625
Overall Width (in)	4.03125
Face Width (in)	3.75

General Specifications

UPC	662289210497
Weight	25.61 LB
Packaged Length	9.10 IN
Packaged Width	9.00 IN
Packaged Height	4.40 IN
