• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Number of Grooves	5
Outside Diameter (in)	14 in
Material	Cast Iron
Overall Length (in)	3.109375 in
Pulley Material	Cast Iron
Pitch Diameter (3V)	13.95
Bushing Used	Q1
Product Type	Multiple Sheaves
Bore (Min) (in)	0.75 in
Belt Section	3V
Bore Type	Split Taper Bushed
Keyway Size	.500
Face Width (in)	2.3125
Bushing Bore Range	2.6875 - 2.6875
Pulley Construction	Spoked
Overall Width (in)	3.0625

General Specifications

UPC	662289270194
Weight	29.42 LB
Packaged Length	14.00 IN
Packaged Width	14.00 IN
Packaged Height	2.50 IN
