• Large Selection - MVP companion sheaves are offered in A/B, C, 5Vand 8V belt sections and from 3-10 grooves giving Browning the largest selection of MVP Companion Sheaves in the industry.
• Statically Balanced - All MVP companion sheaves are statically balanced to assure smooth, vibration free performance.
• VP sheaves consist of a male with a threaded barrel, and a female with a threaded bore.
• The male section with threaded barrel has flat surfaces at 180 degree increments that allow a flat surface for the setscrew to mate with.
• When discs are moved toward each other, the belt rides higher in the groove and the pitch diameter of the sheave is larger which increases the driven speed.
• When discs are moved away from each other, the belt rides lower and the pitch diameter is smaller decreasing the driven speed.

Technical Specifications

Product Type	MVP Sheaves
Pitch Diameter Range (A)	8.2 - 7.1
Material	Cast Iron
Number of Grooves	5
Outside Length (in)	7 in
Pitch Diameter Range (B)	8.7 - 7.3
Ring	5.375
Face Width (Min) (in)	5.3125 in
Type of Bore	Finished
Face Width (Max) (in)	5.6875 in
Outside Diameter (in)	8.68 in
Bore (in)	2.125 in
Belt Section	A, B
Bore Type	Finished with Keyway and SS
Keyway Size	.500
Set Screw Tightening Torque (in-lb)	290
Set Screw Thread	3/8-16 UNC-3AX5/8

General Specifications

UPC	662289294794
Weight	53.92 LB
Packaged Length	9.70 IN
Packaged Width	9.30 IN
Packaged Height	8.70 IN
HTC	8483.50.9040
Country of Origin	United States of America
