• Wrapped construction - Browning offers a full line of wrapped FHP Belts which provides smooth quiet operation. Wrapped FHP Belts are more tolerant to slipping and misalignment than Raw Edge Belts.
• The best features of notched and wrapped belts. Designed for small sheave applications - Browning FHP Belts are formulated for maximum flexibility for use in small diameter sheaves.

Technical Specifications

Pitch Length	29.8
Belt Section	5L
Material	Rubber
Belt Series	FHP Belts
Color	Black
Construction Type	Wrapped
Reinforcing cord material	Polyester
Standards met	ARPM IP-23
Section Size	5L
Overall Width (in)	0.65625 in
Operating Temperature [Max] ºF	140 °F
Product Type	FHP Belt
Outside Length/Diameter (in)	31 in
Width (in)	0.656 in
Cross Section	0.65625
Operating Temperature [Max] ºC	60 °C
Operating Temperature Range	-32 to +140 °F
Resistance Features	Oil & Chemical per ARPM IP-3-2, Static Dissipating per ARPM IP-3-3
Part Height	.375

General Specifications

UPC	662289106363
Weight	0.29 LB
Packaged Length	3.60 IN
Packaged Width	13.60 IN
Packaged Height	0.90 IN
HTC	4010.32.3000
Country of Origin	Mexico
