• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Number of Grooves	5
Datum Diameter (C)	16
Pitch Diameter (C)	16.4
Pulley Material	Cast Iron
Material	Cast Iron
Bushing Used	R1
Outside Diameter (in)	16.4 in
Overall Length (in)	4.796875 in
Product Type	Multiple Sheaves
Belt Section	C
Bore (Min) (in)	1.125 in
Bore Type	Split Taper Bushed
Bushing Bore Range	1.125 - 3.750
Keyway Size	.750

General Specifications

UPC	662289106820
Weight	63.00 LB
Packaged Length	16.40 IN
Packaged Width	16.40 IN
Packaged Height	5.25 IN
