• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Outside Diameter (in)	12.4 in
Overall Length (in)	4.796875 in
Material	Cast Iron
Datum Diameter (C)	12
Pitch Diameter (C)	12.4
Number of Grooves	5
Pulley Material	Cast Iron
Bushing Used	R1
Belt Section	C
Bore (Min) (in)	1.125 in
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Keyway Size	.750
Bushing Bore Range	1.125 - 3.750

General Specifications

UPC	662289246571
Weight	42.70 LB
Packaged Length	12.50 IN
Packaged Width	12.50 IN
Packaged Height	5.25 IN
