• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Bushing Used	R1
Pulley Material	Cast Iron
Overall Length (in)	4.796875 in
Pitch Diameter (C)	11.4
Datum Diameter (C)	11
Outside Diameter (in)	11.4 in
Number of Grooves	5
Material	Cast Iron
Bore (Min) (in)	1.125 in
Belt Section	C
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Face Width (in)	5.25
Bushing Bore Range	1.125 - 3.750
Overall Width (in)	5.25
Keyway Size	.750
Pulley Construction	Webbed

General Specifications

UPC	662289311231
Weight	39.69 LB
Packaged Length	12.50 IN
Packaged Width	12.60 IN
Packaged Height	5.50 IN
