• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Bushing Used	R1
Overall Length (in)	4.171875 in
Pulley Material	Cast Iron
Material	Cast Iron
Datum Diameter (A)	9
Datum Diameter (B)	9.4
Pitch Diameter (A)	9.2
Outside Diameter (in)	9.75 in
Number of Grooves	5
Pitch Diameter (B)	9.7
Bore (Min) (in)	1.125 in
Product Type	Multiple Sheaves
Belt Section	A, B
Bore Type	Split Taper Bushed
Bushing Bore Range	1.125 - 3.750
Face Width (in)	4
Pulley Construction	Webbed
Overall Width (in)	4.15625
Keyway Size	.750

General Specifications

UPC	662289294978
Weight	31.25 LB
Packaged Length	10.40 IN
Packaged Width	10.20 IN
Packaged Height	4.60 IN
