• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Outside Diameter (in)	8.95 in
Model Name	5AB_LG_Sheavemaster
Material	Cast Iron
Bushing Used	SF
Pulley Material	Cast Iron
Number of Grooves	5
Pitch Diameter (B)	8.9
Pitch Diameter (A)	8.4
Datum Diameter (A)	8.2
Datum Diameter (B)	8.6
Bore (Min) (in)	0.5 in
Belt Section	A, B
Product Type	Multiple Sheaves
Bore Type	QD Bushed
Bushing Bore Range	0.500 - 2.938

General Specifications

UPC	662289396566
Weight	24.60 LB
Packaged Length	9.06 IN
Packaged Width	9.06 IN
Packaged Height	4.75 IN
