• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Datum Diameter (A)	7.6
Overall Length (in)	4.171875 in
Outside Diameter (in)	8.35 in
Bushing Used	R1
Material	Cast Iron
Pulley Material	Cast Iron
Datum Diameter (B)	8
Number of Grooves	5
Pitch Diameter (B)	8.3
Pitch Diameter (A)	7.8
Belt Section	A, B
Bore (Min) (in)	1.125 in
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Overall Width (in)	4.15625
Pulley Construction	Webbed
Face Width (in)	4
Keyway Size	.750
Bushing Bore Range	1.125 - 3.750

General Specifications

UPC	662289284733
Weight	24.82 LB
Packaged Length	8.50 IN
Packaged Width	8.50 IN
Packaged Height	4.25 IN
