• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Material	Cast Iron
Pulley Material	Cast Iron
Model Name	5AB_LG_Sheavemaster
Bushing Used	SF
Outside Diameter (in)	7.35 in
Number of Grooves	5
Pitch Diameter (A)	6.8
Pitch Diameter (B)	7.3
Datum Diameter (A)	6.6
Datum Diameter (B)	7
Belt Section	A, B
Bore (Min) (in)	0.5 in
Product Type	Multiple Sheaves
Bore Type	QD Bushed
Face Width (in)	4
Overall Width (in)	4
Bushing Bore Range	0.500 - 2.938
Pulley Construction	Plain

General Specifications

UPC	662289376643
Weight	17.76 LB
Packaged Length	7.88 IN
Packaged Width	7.88 IN
Packaged Height	4.25 IN
