• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Datum Diameter (A)	6
Pitch Diameter (A)	6.2
Outside Diameter (in)	6.75 in
Bushing Used	SK
Model Name	5AB_LG_Sheavemaster
Datum Diameter (B)	6.4
Number of Grooves	5
Material	Cast Iron
Pitch Diameter (B)	6.7
Pulley Material	Cast Iron
Belt Section	A, B
Bore (Min) (in)	0.5 in
Product Type	Multiple Sheaves
Bore Type	QD Bushed
Bushing Bore Range	0.500 - 2.625

General Specifications

UPC	662289386628
Weight	13.97 LB
Packaged Length	7.60 IN
Packaged Width	7.60 IN
Packaged Height	4.30 IN
