• Combination Groove - All Browning B5V Sheaves permit the running of A, 4L, B, 5L and 5V Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Broad horsepower coverage - The B5V is available in 1 through 6 grooves allowing it to cover from 5 to 125 horsepower drives
• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• New Casting design - The B5V castings were developed using CAD and Finite Elements Analysis to determine where to add and eliminate material.

Technical Specifications

Pitch Diameter (A)	8.8
Pulley Material	Cast Iron
Model Name	5B5V-SheaveMaster
Overall Length (in)	4.109375 in
Datum Diameter (B)	9
Material	Cast Iron
Bushing Used	R1
Datum Diameter (A)	8.6
Pitch Diameter (5V)	9.1
Number of Grooves	5
Pitch Diameter (B)	9.3
Outside Diameter (in)	9.28 in
Product Type	Multiple Sheaves
Belt Section	A, B, 5V
Bore (Min) (in)	1.125 in
Bore Type	Split Taper Bushed
Overall Width (in)	4.15625
Keyway Size	.750
Face Width (in)	3.875
Pulley Construction	Webbed
Bushing Bore Range	1.125 - 3.750

General Specifications

UPC	662460344553
Weight	30.98 LB
Packaged Length	10.40 IN
Packaged Width	10.10 IN
Packaged Height	4.60 IN
