• Combination Groove - All Browning B5V Sheaves permit the running of A, 4L, B, 5L and 5V Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Broad horsepower coverage - The B5V is available in 1 through 6 grooves allowing it to cover from 5 to 125 horsepower drives
• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• New Casting design - The B5V castings were developed using CAD and Finite Elements Analysis to determine where to add and eliminate material.

Technical Specifications

Bushing Used	Q1
Number of Grooves	5
Model Name	5B5V-SheaveMaster
Datum Diameter (B)	7.4
Outside Diameter (in)	7.68 in
Material	Cast Iron
Datum Diameter (A)	7
Pitch Diameter (B)	7.7
Pitch Diameter (A)	7.2
Pitch Diameter (5V)	7.5
Pulley Material	Cast Iron
Overall Length (in)	3.890625 in
Bore (Min) (in)	0.75 in
Product Type	Multiple Sheaves
Belt Section	A, B, 5V
Bore Type	Split Taper Bushed
Bushing Bore Range	2.6875 - 2.6875
Pulley Construction	Webbed
Keyway Size	.500
Face Width (in)	3.875
Overall Width (in)	4.25

General Specifications

UPC	662460344522
Weight	20.91 LB
Packaged Length	8.50 IN
Packaged Width	8.60 IN
Packaged Height	4.80 IN
