• Combination Groove - All Browning B5V Sheaves permit the running of A, 4L, B, 5L and 5V Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Broad horsepower coverage - The B5V is available in 1 through 6 grooves allowing it to cover from 5 to 125 horsepower drives
• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• New Casting design - The B5V castings were developed using CAD and Finite Elements Analysis to determine where to add and eliminate material.

Technical Specifications

Material	Cast Iron
Pitch Diameter (A)	6.2
Number of Grooves	5
Bushing Used	Q1
Pitch Diameter (5V)	6.5
Datum Diameter (A)	6
Pulley Material	Cast Iron
Model Name	5B5V-SheaveMaster
Outside Diameter (in)	6.68 in
Overall Length (in)	4.328125 in
Datum Diameter (B)	6.4
Pitch Diameter (B)	6.7
Product Type	Multiple Sheaves
Belt Section	A, B, 5V
Bore (Min) (in)	0.75 in
Bore Type	Split Taper Bushed
Pulley Construction	Plain
Face Width (in)	3.875
Overall Width (in)	4.28125
Keyway Size	.500
Bushing Bore Range	2.6875 - 2.6875

General Specifications

UPC	662460344485
Weight	16.44 LB
Packaged Length	7.19 IN
Packaged Width	7.19 IN
Packaged Height	4.75 IN
