• Combination Groove - All Browning B5V Sheaves permit the running of A, 4L, B, 5L and 5V Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Broad horsepower coverage - The B5V is available in 1 through 6 grooves allowing it to cover from 5 to 125 horsepower drives
• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• New Casting design - The B5V castings were developed using CAD and Finite Elements Analysis to determine where to add and eliminate material.

Technical Specifications

Pitch Diameter (A)	4.4
Pulley Material	Cast Iron
Outside Diameter (in)	4.88 in
Number of Grooves	5
Model Name	5B5V-SheaveMaster
Pitch Diameter (5V)	4.7
Datum Diameter (A)	4.2
Bushing Used	P2
Datum Diameter (B)	4.6
Overall Length (in)	4.703125 in
Material	Cast Iron
Pitch Diameter (B)	4.9
Belt Section	A, B, 5V
Bore (Min) (in)	0.75 in
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Keyway Size	.375
Bushing Bore Range	0.750 - 1.750

General Specifications

UPC	662460344393
Weight	9.98 LB
Packaged Length	6.20 IN
Packaged Width	6.10 IN
Packaged Height	5.10 IN
HTC	8483.50.9040
Country of Origin	Mexico
