• Combination Groove - All Browning B5V Sheaves permit the running of A, 4L, B, 5L and 5V Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Broad horsepower coverage - The B5V is available in 1 through 6 grooves allowing it to cover from 5 to 125 horsepower drives
• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• New Casting design - The B5V castings were developed using CAD and Finite Elements Analysis to determine where to add and eliminate material.

Technical Specifications

Model Name	5B5V-SheaveMaster
Number of Grooves	5
Pitch Diameter (5V)	20.1
Material	Cast Iron
Overall Length (in)	4.109375 in
Pitch Diameter (B)	20.3
Datum Diameter (A)	19.6
Pitch Diameter (A)	19.8
Datum Diameter (B)	20
Bushing Used	R1
Pulley Material	Cast Iron
Outside Diameter (in)	20.28 in
Product Type	Multiple Sheaves
Belt Section	A, B, 5V
Bore (Min) (in)	1.125 in
Bore Type	Split Taper Bushed
Bushing Bore Range	1.125 - 3.750
Overall Width (in)	4.09375
Keyway Size	.750
Pulley Construction	Spoked
Face Width (in)	3.875

General Specifications

UPC	662460344355
Weight	61.40 LB
Packaged Length	20.28 IN
Packaged Width	20.28 IN
Packaged Height	3.87 IN
