• Combination Groove - All Browning B5V Sheaves permit the running of A, 4L, B, 5L and 5V Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Broad horsepower coverage - The B5V is available in 1 through 6 grooves allowing it to cover from 5 to 125 horsepower drives
• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• New Casting design - The B5V castings were developed using CAD and Finite Elements Analysis to determine where to add and eliminate material.

Technical Specifications

Model Name	5B5V-SheaveMaster
Bushing Used	R1
Pitch Diameter (5V)	13.7
Pitch Diameter (B)	13.9
Material	Cast Iron
Pitch Diameter (A)	13.4
Overall Length (in)	4.109375 in
Datum Diameter (B)	13.6
Outside Diameter (in)	13.88 in
Number of Grooves	5
Datum Diameter (A)	13.2
Pulley Material	Cast Iron
Bore (Min) (in)	1.125 in
Belt Section	A, B, 5V
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Bushing Bore Range	1.125 - 3.750
Keyway Size	.750
Face Width (in)	3.875
Overall Width (in)	4.09375
Pulley Construction	Spoked

General Specifications

UPC	662460344317
Weight	39.96 LB
Packaged Length	16.40 IN
Packaged Width	16.20 IN
Packaged Height	4.40 IN
