• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pitch Diameter (B)	18.7
Bushing Used	R1
Datum Diameter (A)	18
Outside Diameter (in)	18.75 in
Material	Cast Iron
Overall Length (in)	4.171875 in
Pulley Material	Cast Iron
Datum Diameter (B)	18.4
Number of Grooves	5
Pitch Diameter (A)	18.2
Product Type	Multiple Sheaves
Bore (Min) (in)	1.125 in
Belt Section	A, B
Bore Type	Split Taper Bushed
Pulley Construction	Spoked
Overall Width (in)	4.15625
Bushing Bore Range	1.125 - 3.750
Keyway Size	.750
Face Width (in)	4

General Specifications

UPC	662289205264
Weight	65.00 LB
Packaged Length	18.75 IN
Packaged Width	4.25 IN
Packaged Height	18.75 IN
