• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pitch Diameter (B)	16.3
Datum Diameter (A)	15.6
Pitch Diameter (A)	15.8
Number of Grooves	5
Bushing Used	R1
Datum Diameter (B)	16
Outside Diameter (in)	16.35 in
Overall Length (in)	4.171875 in
Material	Cast Iron
Pulley Material	Cast Iron
Bore (Min) (in)	1.125 in
Belt Section	A, B
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Bushing Bore Range	1.125 - 3.750
Face Width (in)	4
Keyway Size	.750
Pulley Construction	Spoked
Overall Width (in)	4.15625

General Specifications

UPC	662289305209
Weight	52.61 LB
Packaged Length	16.63 IN
Packaged Width	16.63 IN
Packaged Height	4.25 IN
